HONEYWELL V5328A 2-WAY CAST IRON FLANGE VALVE PN16 BODY

AllActuatorHoneywell

Previous 29 / 40 Next

HONEYWELL V5328A 2-WAY CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1112 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY (MADE IN EUROPE)
HONEYWELL V5328A1112 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY (MADE IN EUROPE)
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3" 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1179 DN65 2-1/2" 2-WAY KVS63 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1179 DN65 2-1/2" 2-WAY KVS63 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1179 DN65 2-1/2" 2-WAY KVS63 CAST IRON FLANGE VALVE PN16 BODY

HONEYWELL V5328A 2-WAY CAST IRON FLANGE VALVE PN16 BODY

Model

​HONEYWELL V5328A1161 DN50 2'' 2-WAY KVS63 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1179 DN65 2-1/2'' 2-WAY KVS63 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL V5328A1187 DN80 3'' 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY (MADE IN CHINA)

HONEYWELL V5328A1112 DN80 3'' 2-WAY KVS100 CAST IRON FLANGE VALVE PN16 BODY (MADE IN EUROPE)



Complete Set Control

HONEYWELL V5328A1179 DN65 2-1/2'' 2-WAY KVS63 CAST IRON FLANGE VALVE PN16 BODY
HONEYWELL ML7421A8035-E 24V 50/60HZ DIRECT COUPLED ELECTRIC VALVE ACTUATOR
HONEYWELL TB7980A 1006 MODULATING TEMPERATURE THERMOSTAT (0-10 VDC OR 2-10VDC) (SINGLE OUTPUT)
HONEYWELL 50014157-001 DUCT TEMPERATURE SENSOR

GENERAL

These single seated valves are used for modulating control of hot / chilled water or steam in heating, ventilating and air conditioning systems.
The valves can be operated by linear actuators ML6420/ML6425 or ML7420/ML7425 or by pneumatic actuators MP953

FEATURES

• Iron body with flanged end connections
• Low seat leakage rate
• High Close-off Pressure Rating (1000kPa)
• Metal to metal seating for long life span
• Self adjusting packing
• Accurate positioning to ensure state of the art temperature control
• Easy mounting of direct coupled electric and pneumatic actuators
• Approved according to DIN 32730

SPECIFICATIONS

Action Stem down to close
Nominal pressure rating PN16
Plug Pressure balanced plug
Flow characteristic Equal percentage, ngl = 3.4
Rangeability 50:1
Leakage rate ≤0.03 % of k VS
Stroke 20 mm
Valve body
End connections Flanged per ISO 7005-2
Material Cast iron (GG25)
Dimensions See Fig. 1
Trim
Seat Stainless steel, replaceable
Stem Stainless steel
Plug Stainless steel, skirt guided
Packing Spring loaded PTFE cone rings
Medium temperature
and pressure 2...120 °C; max. 1600 kPa
120...150 °C; max. 1400 kPa
150...170 °C; max. 1370 kPa
